Valay – Mini VMC

“Valay” is a Sanskrit word for curvature. As the name denotes, it is expert in machining precision curvature geometry. We welcome you on board to come and experience our valay range of products from mini VMC to engraving applications.

The brain of our machines – CNC 5 axis controller is also developed by us in-house, putting user-friendliness and quality at the core. It hosts amazing features including wi-fi file transfer, huge program memory, automatic probing (Z-setter), Remote pendant, industry 4.0 ready, etc to name a few.

Did you know? Valay mini VMC

  • Our own most innovative 5 Axis controller
  • No need to keep host PC on while running programs
  • Automatic fast Z setter
  • Very low maintenance
  • Industry 4.0 ready
  • Program transfer by Wifi / Ethernet
  • Double column design for mechanical rigidity
  • Automatic lubrication system
  • Best price in the segment
  • Attractive ROI

Did you know? Valay mini VMC

  • Is first VMC of India which has its own controller.
  • Is best for single tool production jobs.
  • Is expert in making dies and patterns.
  • Can also do engraving work.
  • Can work upto 18000 rpm
  • Gives very fast return on your investment.
  • Now also available in Automatic Tool Change

Technical Specification

Feature Specification
Machine travel 600mm (X-Axis) X 450mm (Y-Axis) X 300mm (Z-Axis)
Machine travel 600mm (X-Axis) X 450mm (Y-Axis) X 300mm (Z-Axis)
Max speed 15000 mm/min
Drives AC servo
HMI 9 inch QLED Quantum Dot Touchscreen with wide viewing angle
Spindle HSD/Hiteco (Italy) Electrospindle 18000 RPM, 6kW, ER32 (Max tool diameter 20mm)
Positioning accuracy 0.010 mm
Overall weight 1400 kg (approx)
Machine dimensions 1470mm (left to right) X 1725mm (front to back) X 2200 (height)
Coolant Mist/Flood coolant as per requirement
External control Wireless pendant
Electrical rating 8 kVA, 3 phase
